Specifications
| title | M1017EAHX |
| price | $ 285.68 / each |
| Category | Cylindrical Roller Bearings |
| UNSPSC | 31171547 |
| Harmonized Tariff Code | 8482.50.00.00 |
| Manufacturer Name | LINK BELT |
| Inch - Metric | Inch |
| Brand | LINK BELT |
| Weight / LBS | 1.66 |
| Bore | 3.792 Inch | 96.317 Millimeter |
| EAN | 662327105693 |
| Other Features | Standard Capacity | 2 Rib Outer Ring | Narrow Width | Extra Light Series | Oversize OD | Cage on Outer Ring ID |
| Outside Diameter | 5.12 Inch | 130.058 Millimeter |
| Relubricatable | Yes |
| Global Part Number GPN | 449970 |
| Precision Class | RBEC 1 | ISO P0 |
| Width | 0.866 Inch | 22 Millimeter |
| Number of Rows of Rollers | Single Row |
| Retainer | Yes |
| Separable | No |
| Bore Profile | Straight |
| Profile | Roller Assembly with Outer Ring - No Inner Ring |
| Snap Ring | No |
| Internal Clearance | C5-Extra-Extra Loose |
