Specifications
| title | C-UCFS314D1 |
| price | $ 449.19 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | NTN |
| Inch - Metric | Metric |
| Brand | NTN |
| Weight / LBS | 26 |
| Bore | 2.756 Inch | 70 Millimeter |
| EAN | 4547359038569 |
| Other Features | Single Row | Heavy Duty | Wide Inner Race | Open End | Spigot Joint | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 554090 |
| Mounting Method | Set Screw |
| Length Thru Bore | 3.071 Inch | 78 Millimeter |
| Cartridge Pilot Diameter | 7.283 Inch | 185 Millimeter |
| Cartridge Pilot Depth | 0.709 Inch | 18 Millimeter |
| Bolt Spacing | 7.008 Inch | 178 Millimeter |
| Nominal Bolt Circle Diameter Round | 9.9 Inch | 251.7 Millimeter |
| Housing Style | 4 Bolt Square Flange Block |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 22 Millimeter |
| Insert Part Number | UC314D1 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Land Riding |
| Pilot Configuration | With Pilot |
