Specifications
| title | CM-UCF308D1 |
| price | $ 195.07 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | NTN |
| Inch - Metric | Metric |
| Brand | NTN |
| Weight / LBS | 7.5 |
| Bore | 1.575 Inch | 40 Millimeter |
| EAN | 4547359049961 |
| Other Features | Single Row | Heavy Duty | Wide Inner Race | Closed End | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 554117 |
| Mounting Method | Set Screw |
| Length Thru Bore | 2.047 Inch | 52 Millimeter |
| Cartridge Pilot Diameter | 0 Inch | 0 Millimeter |
| Cartridge Pilot Depth | 0 Inch | 0 Millimeter |
| Bolt Spacing | 4.409 Inch | 112 Millimeter |
| Nominal Bolt Circle Diameter Round | 6.2 Inch | 157 Millimeter |
| Housing Style | 4 Bolt Square Flange Block |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 16 Millimeter |
| Insert Part Number | UC308D1 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Land Riding |
| Pilot Configuration | No Pilot |
