Specifications
| title | FC3U263N |
| price | $ 1,237.79 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | REXNORD |
| Weight / kgm | 18.98 |
| Inch - Metric | Inch |
| Brand | LINK BELT |
| Weight / LBS | 41.8 |
| Bore | 3.938 Inch | 100.025 Millimeter |
| EAN | 0793699130843 |
| Other Features | Single Row | Spherical | Standard Duty | Wide Inner Race |
| Relubricatable | Yes |
| Global Part Number GPN | 556468 |
| Mounting Method | Set Screw |
| Length Thru Bore | 4.25 Inch | 107.95 Millimeter |
| Cartridge Pilot Diameter | 8.125 Inch | 206.375 Millimeter |
| Cartridge Pilot Depth | 1.125 Inch | 28.575 Millimeter |
| Bolt Spacing | 6.6 Inch | 167.6 Millimeter |
| Nominal Bolt Circle Diameter Round | 9.4 Inch | 238 Millimeter |
| Housing Style | 4 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 3/4 Inch |
| Insert Part Number | UG263NL |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Contact |
| Pilot Configuration | With Pilot |
