Specifications
| title | FEB22647H |
| price | $ 1,333.12 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | LINK BELT |
| Inch - Metric | Inch |
| Brand | LINK BELT |
| Weight / LBS | 26 |
| Bore | 2.938 Inch | 74.625 Millimeter |
| EAN | 793699501933 |
| Other Features | Double Row | Extended Inner Race |
| Relubricatable | Yes |
| Global Part Number GPN | 246500 |
| Mounting Method | Tapered Adapter Sleeve |
| Length Thru Bore | 3.86 Inch | 98.044 Millimeter |
| Cartridge Pilot Diameter | 0 Inch | 0 Millimeter |
| Cartridge Pilot Depth | 0 Inch | 0 Millimeter |
| Bolt Spacing | 5.563 Inch | 141.3 Millimeter |
| Nominal Bolt Circle Diameter Round | 7.9 Inch | 200 Millimeter |
| Housing Style | 4 Bolt Round Flange Block |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 3/4 Inch |
| Insert Part Number | B22647HL |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Expansion |
| Seals | Floating Labyrinth |
| Pilot Configuration | No Pilot |
