Specifications
| title | QVVCW12V055SC |
| price | $ 665.43 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | QM INDUSTRIES |
| Inch - Metric | Metric |
| Brand | QM INDUSTRIES |
| Weight / LBS | 13 |
| Bore | 2.165 Inch | 55 Millimeter |
| EAN | 883450140577 |
| Other Features | Double Row | Double Nut |
| Relubricatable | Yes |
| Global Part Number GPN | 540795 |
| Mounting Method | V Lock |
| Length Thru Bore | 4.02 Inch | 102.1 Millimeter |
| Cartridge Pilot Diameter | 4.921 Inch | 125 Millimeter |
| Cartridge Pilot Depth | 0 Inch | 0 Millimeter |
| Bolt Spacing | 4.24 Inch | 107.7 Millimeter |
| Nominal Bolt Circle Diameter Round | 6 Inch | 152 Millimeter |
| Housing Style | 4 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 1/2 Inch |
| Insert Part Number | 22212 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Steel |
| Expansion / Non-expansion | Non-expansion |
| Seals | Double Lip Viton |
| Pilot Configuration | With Pilot |
