FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | SM-UCFC207D1 |
| price | $ 138.41 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | NTN |
| Inch - Metric | Metric |
| Brand | NTN |
| Weight / LBS | 3.7 |
| Bore | 1.378 Inch | 35 Millimeter |
| EAN | 4547359186338 |
| Other Features | Single Row | Light Duty | Wide Inner Race | Closed End | Spigot Joint | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 553820 |
| Mounting Method | Set Screw |
| Length Thru Bore | 1.689 Inch | 42.9 Millimeter |
| Cartridge Pilot Diameter | 3.543 Inch | 90 Millimeter |
| Cartridge Pilot Depth | 0.315 Inch | 8 Millimeter |
| Bolt Spacing | 3.063 Inch | 77.8 Millimeter |
| Nominal Bolt Circle Diameter Round | 4.3 Inch | 110 Millimeter |
| Housing Style | 4 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 12 Millimeter |
| Insert Part Number | UC207D1 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Land Riding |
| Pilot Configuration | With Pilot |
