Specifications
| title | UEFCS211-32NP |
| price | $ 231.63 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | ASAHI BEARINGS |
| Weight / kgm | 2.9 |
| Inch - Metric | Inch |
| Brand | AMI BEARINGS |
| Weight / LBS | 6.38 |
| Bore | 2 Inch | 50.8 Millimeter |
| EAN | 0808250291328 |
| Other Features | Single Row | Spherical | Normal Duty |
| Relubricatable | Yes |
| Global Part Number GPN | 529049 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 2.228 Inch | 56.6 Millimeter |
| Cartridge Pilot Diameter | 4.5 Inch | 114.3 Millimeter |
| Cartridge Pilot Depth | 0.625 Inch | 15.875 Millimeter |
| Bolt Spacing | 3.787 Inch | 96.2 Millimeter |
| Nominal Bolt Circle Diameter Round | 5.4 Inch | 138 Millimeter |
| Housing Style | 4 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 1/2 Inch |
| Insert Part Number | UE211-32 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Nickel Coated Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Pilot Configuration | With Pilot |
