FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | UELFU215-215D1 |
| price | $ 216.34 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | NTN |
| Weight / kgm | 3.078 |
| Inch - Metric | Inch |
| Brand | NTN |
| Weight / LBS | 17 |
| Bore | 2.938 Inch | 74.625 Millimeter |
| EAN | 4547359505368 |
| Other Features | Single Row | Light Duty | Wide Inner Race | Has Flinger | With Set Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 552531 |
| Mounting Method | Eccentric Collar |
| Length Thru Bore | 3.622 Inch | 91.999 Millimeter |
| Cartridge Pilot Diameter | 0 Inch | 0 Millimeter |
| Bolt Spacing | 6.266 Inch | 159.156 Millimeter |
| Nominal Bolt Circle Diameter Round | 8.9 Inch | 226.1 Millimeter |
| Housing Style | 4 Bolt Square Flange Block |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 5/8 Inch |
| Insert Part Number | UEL215-215D1W3 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Land Riding |
| Pilot Configuration | No Pilot |
