Specifications
| title | UKFL215+H2315 |
| price | $ 350.77 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | ASAHI BEARINGS |
| Weight / kgm | 6.429 |
| Inch - Metric | Metric |
| Brand | AMI BEARINGS |
| Weight / LBS | 13.4 |
| Bore | 2.559 Inch | 65 Millimeter |
| EAN | 0808250262458 |
| Other Features | Single Row | Spherical | Normal Duty |
| Relubricatable | Yes |
| Global Part Number GPN | 527122 |
| Mounting Method | Adapter Sleeve |
| Length Thru Bore | 2.874 Inch | 73 Millimeter |
| Cartridge Pilot Diameter | 0 Inch | 0 Millimeter |
| Cartridge Pilot Depth | 0 Inch | 0 Millimeter |
| Bolt Spacing | 8.858 Inch | 225 Millimeter |
| Nominal Bolt Circle Diameter Round | 8.9 Inch | 225 Millimeter |
| Housing Style | 2 Bolt Flange Block |
| Number of Mounting Holes | 2 |
| Mounting Bolts | 20 Millimeter |
| Insert Part Number | UK215 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Contact Seal |
| Pilot Configuration | No Pilot |
