Specifications
| title | EMP-205 CXU |
| price | $ 327.53 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | MORSE INDUSTRIAL |
| Inch - Metric | Metric |
| Brand | MORSE INDUSTRIAL |
| Weight / LBS | 3.7 |
| Other Features | Single Row | Medium Duty | Air Handling Duty | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 515737 |
| Mounting Method | Set Screw |
| Length Thru Bore | 1.375 Inch | 34.925 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 4.7 Inch | 119 Millimeter |
| Bolt Spacing Minimum | 4.188 Inch | 106.375Millimeter |
| Base to Center Height | 1.748 Inch | 44.4 Millimeter |
| Bolt Spacing Maximum | 5.188 Inch | 131.775Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | AR-5205-CXU |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Expansion |
| Seals | Felt Labyrinth |
| Housing Material | Cast Iron |
| Mounting Bolts | 1/2 Inch |
| Housing Configuration | 1 Piece Solid |
