Specifications
| title | FSYE 3.7/16 NH |
| price | $ 948.69 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | SKF |
| Inch - Metric | Inch |
| Brand | SKF |
| Weight / LBS | 36.5 |
| Other Features | Double Row | Heavy Duty | Locating Bearing | Open End | With Grub Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 501536 |
| Mounting Method | Stepped Sleeve |
| Length Thru Bore | 3.142 Inch | 79.807 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 11 Inch | 280 Millimeter |
| Bolt Spacing Minimum | 10.563 Inch | 268.3Millimeter |
| Base to Center Height | 3.75 Inch | 95.25 Millimeter |
| Bolt Spacing Maximum | 11.438 Inch | 290.525Millimeter |
| Housing Style | 4 Bolt Pillow Block |
| Insert Part Number | 22218 |
| Number of Mounting Holes | 4 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Trigard |
| Housing Material | Cast Iron |
| Mounting Bolts | 3/4 Inch |
| Housing Configuration | 1 Piece Solid |
