Specifications
| title | MBPPS2-10 |
| price | $ 106.22 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | ASAHI BEARINGS |
| Weight / kgm | 0.18 |
| Inch - Metric | Inch |
| Brand | AMI BEARINGS |
| Weight / LBS | 0.4 |
| Other Features | Single Row | Spherical |
| Relubricatable | No |
| Global Part Number GPN | 526534 |
| Mounting Method | Set Screw |
| Length Thru Bore | 0.866 Inch | 22 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 2.7 Inch | 68 Millimeter |
| Bolt Spacing Minimum | 2.5 Inch | 63.5Millimeter |
| Base to Center Height | 0.875 Inch | 22.225 Millimeter |
| Bolt Spacing Maximum | 2.875 Inch | 73.025Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | MB2-10 |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Contact Seal |
| Housing Material | Stamped Stainless Steel |
| Mounting Bolts | 5/16 Inch |
| Housing Configuration | 1 Piece Solid |
