Specifications
| title | P2B-GTAH-100 |
| price | $ 95.61 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 0.862 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 2.3 |
| Other Features | Single Row | Normal Duty | Air Handling | Wide Inner Race | Thin Wall |
| Relubricatable | Yes |
| Global Part Number GPN | 522363 |
| Mounting Method | Tapered Adapter Sleeve |
| Length Thru Bore | 1.453 Inch | 36.9 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 4.1 Inch | 105 Millimeter |
| Bolt Spacing Minimum | 3.688 Inch | 93.675Millimeter |
| Base to Center Height | 1.438 Inch | 36.525 Millimeter |
| Bolt Spacing Maximum | 4.5 Inch | 114.3Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | INS-GT-100 |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Contact |
| Housing Material | Cast Iron |
| Mounting Bolts | 3/8 Inch |
| Housing Configuration | 1 Piece Solid |
