Specifications
| title | P2B-S2-111L |
| price | $ 352.86 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 3.242 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 7.14 |
| Other Features | Double Row | Has Flinger | With Set Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 521558 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 2.672 Inch | 67.869 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 5.5 Inch | 140 Millimeter |
| Bolt Spacing Minimum | 5.313 Inch | 134.95Millimeter |
| Base to Center Height | 2.125 Inch | 53.98 Millimeter |
| Bolt Spacing Maximum | 5.703 Inch | 144.856Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | INS-S2-111L |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Metallic Labyrinth |
| Housing Material | Cast Iron |
| Mounting Bolts | 1/2 Inch |
| Housing Configuration | 1 Piece Solid |
