Specifications
| title | P2B516-SFXT-211TT |
| price | $ 903.02 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 19.051 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 36.3 |
| Other Features | Double Row | Open End | Corrosion Resistant |
| Relubricatable | Yes |
| Global Part Number GPN | 521330 |
| Mounting Method | Adapter Sleeve |
| Length Thru Bore | 5.234 Inch | 132.944 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 10.4 Inch | 264.2 Millimeter |
| Bolt Spacing Minimum | 10.125 Inch | 257.175Millimeter |
| Base to Center Height | 3.5 Inch | 88.9 Millimeter |
| Bolt Spacing Maximum | 10.625 Inch | 269.875Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | 22216K |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Triple Tect |
| Housing Material | Cast Iron |
| Mounting Bolts | 3/4 Inch |
| Housing Configuration | 2 Piece Split |
