Specifications
| title | P4B522-ISAF-315LE |
| price | $ 1,735.22 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 49.94 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 110 |
| Other Features | Double Row | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 520905 |
| Mounting Method | Adapter Sleeve |
| Length Thru Bore | 4.703 Inch | 119.456 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 13.2 Inch | 335.3 Millimeter |
| Bolt Spacing Minimum | 12.594 Inch | 319.888Millimeter |
| Base to Center Height | 4.938 Inch | 125.425 Millimeter |
| Bolt Spacing Maximum | 14.5 Inch | 368.3Millimeter |
| Housing Style | 4 Bolt Pillow Block |
| Insert Part Number | INS-IP-315L |
| Number of Mounting Holes | 4 |
| Expansion / Non-expansion | Expansion |
| Seals | Metallic Labyrinth |
| Housing Material | Cast Iron |
| Mounting Bolts | 3/4 Inch |
| Housing Configuration | 2 Piece Split |
