Specifications
| title | PB220UR X 1-5/8 |
| price | $ 61.19 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | HUB CITY |
| Inch - Metric | Inch |
| Brand | HUB CITY |
| Weight / LBS | 4.8 |
| Other Features | Single Row | Spherical | Low Base | Has Trash Guard | With Set Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 519862 |
| Mounting Method | Eccentric Collar |
| Length Thru Bore | 1.717 Inch | 43.612 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 5.8 Inch | 146.5 Millimeter |
| Bolt Spacing Minimum | 5.563 Inch | 141.3Millimeter |
| Base to Center Height | 2.063 Inch | 52.4 Millimeter |
| Bolt Spacing Maximum | 5.938 Inch | 150.825Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | B220R |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Nitrile Rubber |
| Housing Material | Cast Iron |
| Mounting Bolts | 1/2 Inch |
| Housing Configuration | 1 Piece Solid |
