Specifications
| title | SYH 1.1/2 FM |
| price | $ 83.95 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | SKF |
| Weight / kgm | 1.939 |
| Inch - Metric | Inch |
| Brand | SKF |
| Weight / LBS | 4.5 |
| Other Features | Single Row | Standard Duty | Narrow Inner Race | Low Base |
| Relubricatable | Yes |
| Global Part Number GPN | 501102 |
| Mounting Method | Eccentric Collar |
| Length Thru Bore | 1.719 Inch | 43.663 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 5.4 Inch | 136 Millimeter |
| Bolt Spacing Minimum | 4.938 Inch | 125.425Millimeter |
| Base to Center Height | 1.938 Inch | 49.225 Millimeter |
| Bolt Spacing Maximum | 5.75 Inch | 146.05Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | YET 208-108 |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | M Seal |
| Housing Material | Cast Iron |
| Mounting Bolts | 1/2 Inch |
| Housing Configuration | 1 Piece Solid |
