Specifications
| title | UETBL207B |
| price | $ 156.62 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | ASAHI BEARINGS |
| Weight / kgm | 0.92 |
| Inch - Metric | Metric |
| Brand | AMI BEARINGS |
| Weight / LBS | 2.02 |
| Other Features | Single Row | Spherical | Normal Duty | Black Housing |
| Relubricatable | Yes |
| Global Part Number GPN | 523586 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 1.728 Inch | 43.9 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 3.3 Inch | 84 Millimeter |
| Bolt Spacing Minimum | 3.252 Inch | 82.6Millimeter |
| Base to Center Height | 1.874 Inch | 47.6 Millimeter |
| Bolt Spacing Maximum | 3.252 Inch | 82.6Millimeter |
| Housing Style | 2 Bolt Tap Base Pillow Block |
| Insert Part Number | UE207 |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Contact Seal |
| Housing Material | Thermoplastic |
| Mounting Bolts | 1 Inch |
| Housing Configuration | 1 Piece Solid |
