Specifications
| title | VPE-135 |
| price | $ 154.23 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | REGAL BELOIT |
| Weight / kgm | 3.68 |
| Inch - Metric | Inch |
| Brand | BROWNING |
| Weight / LBS | 8.1 |
| Other Features | Single Row | Spherical | Intermediate Duty | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 19733 |
| Mounting Method | Eccentric Collar |
| Length Thru Bore | 1.984 Inch | 50.4 Millimeter |
| Actual Bolt Center to Center | 6.9 Inch | 174Millimeter |
| Nominal Bolt Center to Center | 6.8 Inch | 171.5 Millimeter |
| Bolt Spacing Minimum | 0 Inch | 0Millimeter |
| Base to Center Height | 2.5 Inch | 63.5 Millimeter |
| Bolt Spacing Maximum | 0 Inch | 0Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | VE-135 |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Contact |
| Housing Material | Cast Iron |
| Mounting Bolts | 5/8 Inch |
| Housing Configuration | 1 Piece Solid |
