FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
title | ZAF6303 |
price | $ 979.11 / each |
Category | Pillow Block Bearings |
UNSPSC | 31171511 |
Harmonized Tariff Code | 8483.20.40.80 |
Manufacturer Name | REXNORD |
Inch - Metric | Inch |
Brand | REXNORD |
Weight / LBS | 52 |
Other Features | Double Row |
Relubricatable | Yes |
Global Part Number GPN | 494004 |
Mounting Method | Tapered Adapter Sleeve |
Length Thru Bore | 5.141 Inch | 130.581 Millimeter |
Actual Bolt Center to Center | 0 Inch | 0Millimeter |
Nominal Bolt Center to Center | 11 Inch | 280 Millimeter |
Bolt Spacing Minimum | 10.375 Inch | 263.525Millimeter |
Base to Center Height | 4 Inch | 101.6 Millimeter |
Bolt Spacing Maximum | 11.625 Inch | 295.275Millimeter |
Housing Style | 2 Bolt Pillow Block |
Insert Part Number | 6303U |
Number of Mounting Holes | 2 |
Expansion / Non-expansion | Non-expansion |
Seals | Clearance Seal |
Housing Material | Cast Iron |
Mounting Bolts | 3/4 Inch |
Housing Configuration | 1 Piece Solid |
