Specifications
| title | F4B-SCAH-106 |
| price | $ 126.23 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 1.588 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 3.8 |
| Bore | 1.375 Inch | 34.925 Millimeter |
| Other Features | Single Row | Normal Duty | Wide Inner Race | Air Handling |
| Relubricatable | Yes |
| Global Part Number GPN | 549466 |
| Mounting Method | Set Screw |
| Length Thru Bore | 1.531 Inch | 38.9 Millimeter |
| Cartridge Pilot Diameter | 0 Inch | 0 Millimeter |
| Cartridge Pilot Depth | 0 Inch | 0 Millimeter |
| Bolt Spacing | 3.625 Inch | 92.08 Millimeter |
| Nominal Bolt Circle Diameter Round | 5.1 Inch | 130 Millimeter |
| Housing Style | 4 Bolt Square Flange Block |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 1/2 Inch |
| Insert Part Number | INS-SC-106 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Contact |
| Pilot Configuration | No Pilot |
