FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | UCHA20926 |
| price | $ 99.53 / each |
| Category | Hanger Unit Bearings |
| UNSPSC | 31171513 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | FYH |
| Inch - Metric | Inch |
| Brand | FYH |
| Weight / LBS | 3.748 |
| Bore | 1.625 Inch | 41.275 Millimeter |
| Other Features | Single Row | Spherical | NBR Seal | Has Slinger |
| Relubricatable | Yes |
| Mounting Method | Set Screw |
| Length Thru Bore | 1.937 Inch | 49.2 Millimeter |
| Base to Center Height | 3.25 Inch | 82.55 Millimeter |
| Housing Outside Diameter | 4.25 Inch | 107.95 Millimeter |
| Housing Overall Length | 5.344 Inch | 135.738 Millimeter |
| Mounting Thread | 1 Straight Pipe Female |
| Insert Material | Steel |
| Housing Style | Hanger Unit |
| Insert Part Number | UC209-26 |
| Rating | Normal Duty |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Contact |
